PORT PROCESSORS/MODULES
940043-002 INTEGRATED ENTERPRISE NETWORK 3-15
Table 3-3 lists the jumper definitions for the CID63 port processor.
Table 3-3 CID63 Jumper Definitions
JUMPER DESCRIPTION FACTORY SETTING
JT1 IEN 500/CID63 Mode Not Installed: CID63 - Open, IEN 500 - Closed
JT2 N/A N/A
JT3 N/A N/A
JT4 N/A N/A
JT5 N/A N/A
JT6 Battery ON/OFF Battery On: Pins 2 & 3 connected
JT7 N/A N/A
JT9 N/A N/A
JT10 N/A N/A
JT12 N/A N/A
JT13 N/A N/A
JT14 Board ID Pins 1 & 2 open
JT15 N/A N/A
JT16 Board ID Pins 1 & 2 open
JT17 Chassis Ground Not Installed: CID63 - Open, IEN 500 - Closed
JT18 Second 2-wire Telco line Not Installed: CID63 - Closed, IEN 500 - Closed
JT19 Second 2-wire Telco line Not Installed: CID63 - Closed, IEN 500 - Closed
JT20 Second 2-wire Telco line Not Installed: CID63 - Open, IEN 500 - Closed
JT21 Second 2-wire Telco line Not Installed: CID63 - Open, IEN 500 - Closed
JT22 Telco Ground Installed: CID63 - Closed, IEN 500 - Open
JT23 Chassis Ground Not Installed
JT24 Telco Ground to Chassis Ground Not Installed: CID63 - Closed, IEN 500 - Closed
JT25 Second 2-wire Telco line Not Installed: CID63 - Open, IEN 500 - Closed
JT26 First Telco line connected to RJ11 Not Installed: CID63 - Closed, IEN 500 - Closed
JT27 First Telco line connected to RJ11 Not Installed: CID63 - Closed, IEN 500 - Closed
JT28 First Telco line connected to RJ11 Not Installed: CID63 - Closed, IEN 500 - Closed
JT29 Second Telco line connected to RJ11 Installed: CID63 - Closed, IEN 500 - Closed
JT30 First Telco line connected to RJ11 Installed: CID63 - Closed, IEN 500 - Closed
JT31 Second Telco Ground to Chassis Ground Installed: CID63 - Closed, IEN 500 - Closed
JT32 N/A N/A
JT33 N/A N/A
JT34 N/A N/A
JT35 N/A N/A
