CHAPTER 3
3-34 IEN HARDWARE REFERENCE 940043-002
Table 3-11 lists the jumper definitions for the LTR61, LTR61B and LTR61H port processors.
Table 3-11 LTR61, LTR61B and LTR61H Jumper Descriptions
JUMPER DESCRIPTION FACTORY SETTING
JT7 Battery Backup On/Off Battery On: Pins 2 & 3 connected.
JT9 Chassis Ground to TROLI Do not connect.
