Powermax30 AIR Service Manual 808850 161
6 – Power Supply Component Replacement
4. Use an 8 mm (5/16 inch) wrench to remove the hex nuts from the 3 retaining screws that secure the internal
compressor to the base of the power supply.
5. Remove the metal washer from each retaining screw.
Figure 73
2
2
