Precautions for Handling
Intro-10
5. Do not apply radial load and load moment to the rod. (For rod type)
Loads can only be applied in the axial direction matching the rod axis.
6. If return operations are continued over a short distance, they may rapidly
degrade the film of grease.
Continuous return operation within a distance less than 30mm may cause the grease film to degrade
rapidly.
As a guideline, in every 5,000 to 10,000 cycles, have approximately 5 cycles of return operation over a
50mm distance or more to regenerate the oil film. Continued use of the actuator in that state may lead
to breakdown.
In extreme cases, flaking may occur on the guide or ball screw.
7. Do not attempt to have sliders or rods collide with an obstacle at high speed.
This may damage other mechanical parts.
8. Grease has been applied to the outer periphery of the rod for the rod type.
Protect the peripheral equipment if grease adhesion negatively affects them.
9. The "Allow ** mm or more" indicated in the External Dimensions is intended to
enable wiring without excessive force applied to the cable.
Allow *** mm or more cable linearity.
