1.2 Mechanical specifications
1-66
1. Specifications
Allowable offset amount, allowable overhang distance
Type
Allowable offset amount
Allowable overhang
distance
EC-RR6 100mm 100mm
EC-RR7 100mm 100mm
Caution
Keep the radial load acting on the rod within the allowable offset amount and overhang
distance for use.
If the allowable values are exceeded, this may lead to vibration, shortened product life, or
damage.
Overhang distance
(Rod length direction)
Offset amount
(Rod perpendicular direction)
To Next Page
