240
INTELLIGENT ACTUATOR
Part 4 Commands
ITER (Repeat)
Command, declaration
Extension condition
(LD, A, O, AB, OB)
Input condition
(I/O, flag)
Command,
declaration
Operand 1 Operand 2
Output
(Output, flag)
Optional Optional ITER Prohibited Prohibited CP
[Function] Forcibly switch the control to EDDO while in a DO loop.
[Example 1] DWEQ 1 0 Repeat the commands up to an EDDO command while
variable 1 contains “0.”
:
600 ITER
:
Forcibly switch the control to an EDDO command and
perform end judgment, if flag 600 is ON.
EDDO
EDDO (End DO WHILE)
Command, declaration
Extension condition
(LD, A, O, AB, OB)
Input condition
(I/O, flag)
Command,
declaration
Operand 1 Operand 2
Output
(Output, flag)
Prohibited Prohibited EDDO Prohibited Prohibited CP
[Function] Declare the end of a loop that began with DW.
If the DW condition is not satisfied, the program will proceed to the step next to this
command.
[Example 1] Refer to the section on DW.
To Next Page
