Part 4 Commands
Schematic diagram of placement-point positions based on the above program
 The number shown at the top right of each circle indicates a palletizing position number.
 Count in PX-axis direction = 5, Count in PY-axis direction = 7
 Pitch in PX-axis direction: 40
 Pitch in PY-axis direction: 30
 Zigzag offset: 20
 Zigzag count: 4
Reference point
(X, Y, Z)
= (100, 100, 100)
Axis-1 direction
PY-axis
PX-axis
Axis-2 direction
5
4
3
2
1
20
14
23
32
9
18
27
13
22
31
8
17
26
12
21 30
7
16
25
11
20
29
6
15
24
10
19
28
40
30
