308 Implementing the IBM Storwize V5000 Gen2 with IBM Spectrum Virtualize V8.1

3. Next, the GUI displays the underlying CLI commands being run to create the mirrored

volume and indicates completion as shown in Figure 6-18.

Figure 6-18 Task complete: creating Mirrored volume

Volume Creation with Capacity Saving options

The Volume Creation operation also provides, using the Capacity Savings parameter, the

ability to alter the provisioning of a Basic or Mirrored volume into Thin-provisioned or

Compressed.

Note: When creating a Mirrored volume by using this menu, you are not required to

specify the Mirrored Sync rate. It defaults to 2 MBps. Customization of this

synchronization rate can be done by using the Custom option.
