364 Implementing the IBM Storwize V5000 Gen2 with IBM Spectrum Virtualize V8.1
Mapping storage
Follow the instructions that are shown in the Map Storage panel that is shown in Figure 7-16
and click Next. Record all of the details carefully because the information is used in later
panels. Table 7-2 shows an example table for you to capture the information that relates to the
external storage system LUs.
Figure 7-16 Directions to record migration data
Table 7-2 Example table to capture the external LU information
LU name Controller Array SCSI ID Host name Capacity
V3700external0 Node2 V3700 0 50 GiB
V3700external1 Node1 V3700 1 50 GiB
V3700external2 Node2 V3700 2 50 GiB
V3700external3 Node1 V3700 3 50 GiB
V3700external4 Node2 V3700 4 50 GiB
V3700external5 Node1 V3700 5 50 GiB
SCSI ID: Record the SCSI ID of the LUs to which the host is originally mapped. Certain
operating systems do not support the change of the SCSI ID during the migration.
