AFL-xxx-CX2 Panel PC
Page 146
Step 13:
The destination folder selection wi
ndow appears (
Figure 6-38
).
Figure 6-38: USB 2.0 InstallShield Wizard Welc
ome Screen
Step 14:
Change the inst
allation directory if needed (
Figure 6-38).
Step 15:
Click
N
EXT
to continue the inst
allation.
