AFL-xxx-CX2 Panel PC
Page 13
1.4.4.4 AFL-12B-CX2
SPECIFICATION AFL-12B-CX2
Model Toshiba LTA121C50F
Size 12.1”
Resolution 1024 x 768
Active Area (mm) 245.76 x 184.32
Pixel Pitch (mm) 0.24 x 0.24
LCD Color 262K
View Angle (H/V) 120/100
Brightness (cd/m
2
) 400
Contrast Ratio 500:1
Supply Voltage (V) 3.3 V
Backlight 2 CCFL
Backlight MTBF (hrs.) 50000
Dimensions (WxHxD)(mm) 278.3 x 209.0 x 12.0
Table 1-7: AFL-12B-CX2 TFT LCD Monitor Specifications
1.4.5 Touch Screen Specifications
The AFL-xxx-CX2 series come with an analog resistive type touch panel. Table 1-8 lists
the touch panel specifications.
SPECIFICATION AFL-07A-CX2 AFL-08AH-CX2 AFL-10A-CX2 AFL-12B-CX2
Model 75200-107040
4C-RS
75200-1084403B
-01-RS
75200-1104502
A-RS
75200-1121505
B-RS
Type Analog Resistive Type Touch Panel
Wire Type 4-wire 5-wire
Viewing Area (mm) 154.90 x 93.94 130.75 x 173.38 219.8 x 166.8 188.0 x 250.0
Active Area (mm) 152.40 x 91.44 127.78 x 170.38 212.1 x 159.3 185.0 x 246.0
Total Transmission 78%
Maximum Voltage DC 7 V
Connector Type FPC.
Operating Temperature -10°C ~ 60°C -10°C ~ 50°C
