IEI Technology AFL-xxx-CX2 User Manual

AFL-xxx-CX2 Panel PC
Page 30
2.12.1 Touch Screen Connector
CN Label: JP1
CN Type:
9-pin connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-1
The touch screen connector connects to the touch screen on the front panel of the
AFL-xxx-CX2.
PIN DESCRIPTION
1 X+
2 X-
3 Y+
4 SENSE
5 X+
6 X-
7 Y+
8 Y-
9 GND
Table 2-1: Touch Screen Connector
2.12.2 GPIO Connector
CN Label: JP2
CN Type:
4-pin connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-2
The GPIO connector is connected to external devices and can be programmed for
external machine control. As standard, the GPIO connector is not used in the
AFL-xxx-CX2, but is still functional.
