IEI Technology AFL-xxx-CX2 User Manual

AFL-xxx-CX2 Panel PC
Page 39
PIN DESCRIPTION
1 GND
2 GND
3 12 V
Table 2-16: 12 V Power Connector
2.12.17 COM2 RS-232/422/485 Serial Port Connector
CN Label: CN16
CN Type:
DB-9 male
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-17
The COM2 serial port connector provides an RS-232, RS-422 or RS-485 data connection
to an attached device.
PIN RS-232 mode RS-422 mode RS-485 mode
1 DCD2 TX- Data-
2 RX2 TX+ Data+
3 TX2
4 DTR2
5 GND
6 DSR2 RX-
7 RTS2 RX+
8 CTS2
9 RI2
Table 2-17: COM2 Serial Port Connector
2.12.18 COM1 RS-232 Serial Port Connector
CN Label: CN17
CN Type:
DB-9 male
CN Location:
See
Figure 2-9
