IEI Technology AFL-xxx-CX2 User Manual

AFL-xxx-CX2 Panel PC
Page 11
Specification AFLMB-CX2-R10
IDE One 44-pin IDE connects to two IDE devices
Touch Screen Controller DMC9000
Power Supply DC 12 V In
Dimensions 102 mm x 186 mm
Table 1-3: Motherboard Specifications
1.4.4 Flat Panel Screen Specifications
The AFL-xxx-CX2 series come with a TFT LCD monitor at the front of the flat panel PC
(see
Figure 1-2). The specifications for the LCD monitor are shown below.
1.4.4.1 AFL-07A-CX2
SPECIFICATION AFL-07A-CX2
Model Data Image FG0700A1DSCWBGL1
Size 7”
Resolution 800 x 480
Active Area (mm) 152.4 x 91.44
Pixel Pitch (mm) 0.1905 x 0.1905
LCD Color 262K
View Angel (H/V) 140/100
Brightness (cd/m
2
) 350
Contrast Ratio 400:1
Supply Voltage (V) 3.3
Backlight 1 CCFL
Backlight MTBF (hrs.) 50000
Dimensions (WxHxD)(mm) 165 x 104 x 5.5
Table 1-4: AFL-07A-CX2 TFT LCD Monitor Specifications
1.4.4.2 AFL-08AH-CX2
SPECIFICATION AFL-08AH-CX2
Model AUO G084SN05
