CN Pinouts:
See
Table 2-23
The CPU fan connector connects to a cooling fan. The cooling fan is not implemented on
the AFL-xxx-CX2.
PIN DESCRIPTION
1 NC
2 +5 V
3 GND
Table 2-23: CPU Fan Connector
2.12.24 USB Connectors (Internal)
CN Label: USB3
CN Type:
8-pin header
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-24
The USB connectors connect to USB devices.
PIN DESCRIPTION PIN DESCRIPTION
1 FUSEVCC 5 FUSEVCC
2 FUSB0- 6 FUSB1-
3 FUSB0+ 7 FUSB1+
4 GND 8 GND
Table 2-24: USB Connectors
