AFL-xxx-CX2 Panel PC
Page 76
4.5.1 AT/ATX Power Selection (JP18)
This jumper sets the power as using AT power or ATX power.
JP18 Description
1-2 closed ATX power
1-2 open AT power
Table 4-1: AT/ATX Power Selection
4.5.2 Clear CMOS (JP5)
The Clear CMOS jumper is for resetting the BIOS. To reset the BIOS, turn off the
computer, move the jumper to the “Clear CMOS setup” position, turn on the computer for
5 seconds, turn off, then set the jumper to the normal position. The BIOS is then returned
to default settings.
JP5 DESCRIPTION
1-2 Normal operation
2-3 Clear CMOS setup
Table 4-2: Clear CMOS
4.5.3 CompactFlash
®
Master/Slave Selection (JP8)
This jumper sets the CompactFlash® disk as the IDE master or the IDE slave. The
CompactFlash® master/slave jumper is a part of jumper JP8, only the pins relating to this
setting are covered.
JP8 Description
9-10 Open Master
9-10 Closed Slave
Table 4-3: CompactFlash® Master/Slave Selection
