AFL-xxx-CX2 Panel PC
Page 15
Specification Bluetooth Module
Operating System Windows XP, Windows 2000, Windows 98SE, Windows Me
Table 1-9: Bluetooth Module Specifications
1.4.7 Optional HSDPA Module Specifications
The HSDPA module is one of the OEM options for the AFL-xxx-CX2 series. The technical
specifications of the HSDPA module are listed in
Table 1-10.
Specification
HSDPA Module
EDG/HSDPA/GSM Air Interface Quad-band operation GSM850, EGSM 900, DCS 1800, PCS
1900
GSM Power Class 4 (2 W) for 850/900 bands
GSM Power Class 1 (1 W) for 1800/1900 bands
EDFE class E2 (+27dBm in 850/900 bands,
+26dBm in 1800/1900 bands)
GSM/HSDPA Rel ’97; PCS 1900 Rel ’98; EHSDPA Rel ’99
compliant
EHSDPA/HSDPA (PS) Feature
Set
HSDPA Class 10, coding schemes 1-4
EDGE Class 10, Multi-slot classes 1-9
HSDPA/EHSDPA Class B type 1 MT
Link Adaptation
Incremental redundancy (IR)
USB Interface USB 2.0 +5 V DC
SIM Card Interface 3.0 V interface
Temperature -30°C ~ +65°C
Humidity Up to 95%, non-condensing
Dimensions 109.3 mm x 42.7 mm x 17.7 mm
Operating System Windows 2000/XP Home/XP Professional
Table 1-10: HSDPA Module Specifications
1.5 Dimensions
The dimensions of all the AFL-xxx-CX2 models are shown in the subsections below.
