IEI Technology AFL-xxx-CX2 User Manual

AFL-xxx-CX2 Panel PC
Page 42
2.12.22 LVDS Connector
CN Label: LVDS1
CN Type:
30-pin crimp
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-22
The LVDS connector connects to the LCD panel and provides the data for the display of
images on the screen.
PIN DESCRIPTION PIN DESCRIPTION
1 GND 2 GND
3 LDC3+ 4 LDC3-
5 LCLk1+ 6 LCLk1-
7 LDC2+ 8 LDC2-
9 LDC1+ 10 LDC1-
11 LDC0+ 12 LDC0-
13 GND 14 GND
15 LDC7+ 16 LDC7-
17 LCLK2+ 18 LCLK2-
19 LDC6+ 20 LDC6-
21 LDC5+ 22 LDC5-
23 LDC4+ 24 LDC4-
25 GND 26 GND
27 VDD 28 VDD
29 VDD 30 VDD
Table 2-22: LVDS Connector
2.12.23 CPU Fan Connector
CN Label: FAN1
CN Type:
3-pin wafer
CN Location:
See
Figure 2-9
