AFL-xxx-CX2 Panel PC
Page 10
SPECIFICATION AFL-07A-CX2 AFL-08AH-CX2 AFL-10A-CX2 AFL-12B-CX2
Power 12 V, 48 W DC power adapter 12 V, 60 W DC power adapter
Power Consumption 30 W 30 W 36 W 41 W
Mounting Feature Panel, Rack, Wall, Arm, Stand
Operating Temperature 0ºC ~45ºC
Storage Temperature -20ºC ~60ºC
Relative Humidity 10% ~ 80% RH, non-condensing
Dimension (W x H x D) 226 x 140 x 41 234 x 184 x 42 276 x 227 x 50.7 304 x 246 x 56
Net Weight 0.6 kg 0.8 kg 1.4 kg 1.8 kg
Front Panel Protection IP 64 compliant
Safety & EMI CE / FCC / EMC / CB
Table 1-2: System Specifications
1.4.3 Motherboard Specifications
The AFL-xxx-CX2 series come with an AFLMB-CX2-R10 motherboard. The technical
specifications of the motherboard are listed in
Table 1-3.
Specification AFLMB-CX2-R10
CPU VIA EDEN ULV 1.0 GHz
Chipset VIA CX700M
Display CRT integrated in CX700M
Supports panel resolution from VGA to UXGA (1600 x 1200)
Supports one Dual-Channel / two Single-Channel LVDS panel
Memory Supports one 200-pin 400/533 MHz DDR2 SDRAM SO-DIMM module
up to 1 GB
Extension One mini PCI slot
BIOS AMI BIOS
SSD CFII
Super I/O N/A for legacy free
Audio Realtek ALC888 (High Definition Audio)
LAN 10/100/1000 Base-T RTL8110SC
COM 1 x RS-232 serial port
1 x RS-232/422/485 serial port
