AFL-xxx-CX2 Panel PC
Page 14
SPECIFICATION AFL-07A-CX2 AFL-08AH-CX2 AFL-10A-CX2 AFL-12B-CX2
Operating Humidity 20% ~ 90% RH
Storage Temperature -20°C ~ 70°C
Storage Humidity 20% ~ 90% RH
Dimensions 165 x 104 x 1.4 145.5 x 188 x 2.1 238.8x 188.7 x
2.6
204 x 268 x 2.1
Table 1-8: Touch Panel Specifications
1.4.6 Bluetooth Module Specifications
The AFL-xxx-CX2 series are all integrated with a Bluetooth module. The Bluetooth module
enables the transmission between various peripheral devices through a Bluetooth network.
The peripheral devices may include:
Headsets
Barcode readers
PDA
Printers
Cell phones
The technical specifications of the Bluetooth module are listed in
Table 1-9.
Specification Bluetooth Module
Standard Bluetooth v2.0
Frequency Band 2.402GHz~2.480GHz unlicensed ISM band
Modulation Method GFSK for 1 Mb/s
π/4-DQPSK for 2 Mb/s
8-DPSK for 3 Mb/s
Spread Spectrum FHSS (Frequency Hopping Spread Spectrum)
RF Output Power Class 2 (under 4dBm)
Antenna Terminal 50 Ohms
DC Power DC 3.3 V or DC 5 V
I/O Interface USB 2.0 interface
Two GPIO Interface LED link indicator interface
Dimensions 35 mm x 11 mm
