AFL-xxx-CX2 Panel PC
Page 31
PIN DESCRIPTION
1 +5 V
2 GND
3 OUT0
4 INT0
Table 2-2: GPIO Connector
2.12.3 RFID Connector
CN Label: JP3
CN Type:
10-pin connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-3
The RFID connector can be connected to an RFID connector. As standard, the RFID
connector is not used in the AFL-xxx-CX2, but is still functional.
PIN DESCRIPTION PIN DESCRIPTION
1 +5 V 2 +5 V
3 GND 4 MCU_UR
5 RX 6 AUTO_CLK
7 TX 8 AUTO_DATA
9 GND 10 GND
Table 2-3: RFID Connector
2.12.4 Front Panel Connectors
CN Label: JP8
CN Type:
10-pin connector (first 8 pins for front panel)
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-4
