AFL-xxx-CX2 Panel PC
Page 41
CN Type:
SATA connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-20
The SATA connectors connect to SATA hard drives and SATA CD-ROMs.
PIN DESCRIPTION
1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND
Table 2-20: SATA Connector
2.12.21 Battery Connector
CN Label: BT1
CN Type:
2-pin box header
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-21
The battery connector connects to the system battery. The system battery provides power
to retain basic settings and the system clock.
PIN DESCRIPTION
1 +3.3 V
2 GND
Table 2-21: Battery Connector
