IEI Technology AFL-xxx-CX2 User Manual

AFL-xxx-CX2 Panel PC
Page 40
CN Pinouts:
See
Table 2-18
The COM1 serial port connector provides an RS-232 data connection to attached devices.
PIN DESCRIPTION
1 DCD1
2 RX1
3 TX1
4 DTR1
5 GND
6 DSR1
7 RTS1
8 CTS1
9 RI1
Table 2-18: COM1 Serial Port Connector
2.12.19 Digital Microphone Input Connector
CN Label: DMIC_1
CN Type:
3-pin connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-19
The digital microphone input allows digital audio data to be collected.
PIN DESCRIPTION
1 MIC_CLK
2 MIC_DATA
3 GND
Table 2-19: Digital Microphone Input Connector
2.12.20 SATA Ports
CN Label: SATA1 and SATA2
