IEI Technology AFL-xxx-CX2 User Manual

AFL-xxx-CX2 Panel PC
Page 33
The keypad connector connects to an numeric keypad for access control systems.
PIN DESCRIPTION
2 VOL+
4 VOL-
6 BRIGHT+
8 BRIGHT-
10 LCD ON_OFF
12 GND
Table 2-6: Keypad Connector
2.12.7 Backlight Connector
CN Label: CN1
CN Type:
6-pin box header
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-7
The backlight connector provides power for the LCD panel backlight.
PIN DESCRIPTION PIN DESCRIPTION
1 12 V 2 12 V
3 BLON 4 ADJ
5 GND 6 GND
Table 2-7: Backlight Connector
2.12.8 CPLD Connector
CN Label: CN2
CN Type:
6-pin connector
CN Location:
See
Figure 2-9
CN Pinouts:
See
Table 2-8
The CPLD connector connects to a complex programmable logic device.

IEI Technology AFL-xxx-CX2 Specifications

General

Brand	IEI Technology
Model	AFL-xxx-CX2
Category	Touch Panel
Language	English
