HD2 Series Inverter Basic Operation Guidelines
-98-
Setting
Function
Description
75
Tension control pre-drive
If the terminal is valid when the tension control function is
enabled, tension control pre-drive is performed.
76
Disable roll diameter
calculation
If the terminal is valid when the tension control function is
enabled, roll diameter calculation is disabled.
77
Clear alarm display
Used to clear the alarm display when the tension control
function is enabled.
78
Manual braking of tension
control
If the terminal is valid when the tension control function is
enabled, manual braking is activated.
79
Trigger forced feeding
interrupt
If the terminal is valid when the tension control function is
enabled, a feeding interrupt signal is triggered forcibly.
80
Initial roll diameter 1
Used to select different initial roll diameters by combining
with the initial roll diameter 2 when the tension control
function is enabled.
81
Initial roll diameter 2
Used to select different initial roll diameters by combining
with the initial roll diameter 1 when the tension control
function is enabled.
82
Trigger fire mode control
In fire mode, if the terminal is valid, the fire mode control
signal is triggered.
83
Switch tension PID
parameters
Used to switch two PID parameter groups when the
tension control function is enabled. The first group is
used by default. If the terminal is valid, the second group
is used.
84–95
Reserved
Related parameter list:
Function
code
Name
Description
Default
value
P05.00
HDI input type
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0x00
P05.01
Function of S1 terminal
0: No function
1: Forward running
2: Reverse running
3: 3-wire control/Sin
4: Forward jogging
5: Reverse jogging
1
P05.02
Function of S2 terminal
4
P05.03
Function of S3 terminal
7
P05.04
Function of S4 terminal
0
P05.05
Function of HDIA terminal
0
