HD2 Series Inverter Basic Operation Guidelines
-126-
Function
code
Name
Description
Default
value
13: Phase loss on input side (SPI)
14: Phase loss on output side (SPO)
15: Rectifier module overheat (OH1)
16: Inverter module overheat (OH2)
17: External fault (EF)
18: Modbus/Modbus TCP communication
fault (CE)
19: Current detection fault (ItE)
20: Motor autotuning fault (tE)
21: EEPROM operation fault (EEP)
22: PID feedback offline fault (PIDE)
23: Braking unit fault (bCE)
24: Running time reached (END)
25: Electronic overload (OL3)
26: Keypad communication error (PCE)
27: Parameter upload error (UPE)
28: Parameter download error (DNE)
29: Profibus DP communication fault
(E-DP)
30: Ethernet communication fault (E-NET)
31: CANopen communication fault
(E-CAN)
32: To-ground short-circuit fault 1 (ETH1)
33: To-ground short-circuit fault 2 (ETH2)
34: Speed deviation fault (dEu)
35: Mal-adjustment fault (STo)
36: Underload fault (LL)
37: Encoder offline fault (ENC1O)
38: Encoder reversal fault (ENC1D)
39: Encoder Z pulse offline fault (ENC1Z)
40: Safe torque off (STO)
41: Channel H1 safety circuit exception
(STL1)
42: Channel H2 safety circuit exception
(STL2)
43: Channel H1 and H2 exception (STL3)
44: Safety code FLASH CRC check fault
(CrCE)
55: Duplicate expansion card type (E-Err)
