IMO HD2-3.7A-43 - Page 160

HD2 Series Inverter Function Parameter List
-151-
Function
code
Name
Description
Default
value
Modify
P03.14
Setting source of
FWD rotation
frequency upper
limit in torque
control
0: Keypad (P03.16)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus/Modbus TCP communication
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: Pulse frequency HDIB
10: EtherCAT/PROFINET/EtherNet IP
communication
11: Programmable card
12: Reserved
Note: For these settings, 100% corresponds to the
max. frequency.
0
○
P03.15
Setting source of
REV rotation
frequency upper
limit in torque
control
0: Keypad (P03.17)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus/Modbus TCP communication
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: Pulse frequency HDIB
10: EtherCAT/PROFINET/EtherNet IP
communication
11: Programmable card
12: Reserved
Note: For these settings, 100% corresponds to the
max. frequency.
0
○
P03.16
FWD rotation
frequency upper
limit set through
keypad in torque
control
Used to specify frequency limits. 100%
corresponds to the max. frequency. P03.16
specifies the upper-limit frequency when
P03.14=1; P03.17 specifies the upper-limit
frequency when P03.15=1.
50.00Hz
○
