HD2 Series Inverter Function Parameter List
-166-
Function
code
Name
Description
Default
value
Modify
62: Reserved
63: Enable servo
64: Limit of forward run
65: Limit of reverse run
66: Zero out encoder counting
67: Pulse increase
68: Enable pulse superimposition
69: Pulse decrease
70: Electronic gear selection
71: Switch to master
72: Switch to slave
73: Reset the roll diameter
74: Switch winding/unwinding
75: Pre-drive
76: Disable roll diameter calculation
77: Clear alarm display
78: Manual braking
79: Trigger forced feeding interrupt
80: Initial roll diameter 1
81: Initial roll diameter 2
82: Trigger fire mode control
83: Switch tension PID parameters
84–95: Reserved
P05.07
Reserved
0–65535
0
●
P05.08
Polarity of input
terminal
This parameter specifies the polarity of input
terminals.
When the bit is set to 0, input terminal polarity is
positive.
When the bit is set to 1, input terminal polarity is
negative.
0x000–0x3F
0x000
○
P05.09
Digital filter time
Set S1–S4, filter time of HDI terminal sampling. In
cases where interference is strong, increase the
value of this parameter to avoid mal operation.
0.000–1.000s
0.010s
○
P05.10
Virtual terminal
setting
0x000–0x3F (0: disable, 1: enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
0x00
◎
