HD2 Series Inverter Function Parameter List
-171-
Function
code
Name
Description
Default
value
Modify
P05.36
Corresponding
setting of upper
limit of AI2
Setting range of P05.27: -300.0%–300.0%
Setting range of P05.28: 0.000s–10.000s
Setting range of P05.29: -10.00V–P05.31
Setting range of P05.30: -300.0%–300.0%
Setting range of P05.31: P05.29–P05.33
Setting range of P05.32: -300.0%–300.0%
Setting range of P05.33: P05.31–P05.35
Setting range of P05.34: -300.0%–300.0%
Setting range of P05.35: P05.33–10.00V
Setting range of P05.36: -300.0%–300.0%
Setting range of P05.37: 0.000s–10.000s
100.0%
○
P05.37
Input filter time of
AI2
0.030s
○
P05.38
HDIA high-speed
pulse input
function
0: Set input via frequency
1: Reserved
2: Input via encoder, used in combination with
HDIB
0
◎
P05.39
Lower limit
frequency of
HDIA
0.000 kHz – P05.41
0.000
kHz
○
P05.40
Corresponding
setting of lower
limit frequency of
HDIA
-300.0%–300.0%
0.0%
○
P05.41
Upper limit
frequency of
HDIA
P05.39 –50.000kHz
50.000
kHz
○
P05.42
Corresponding
setting of upper
limit frequency of
HDIA
-300.0%–300.0%
100.0%
○
P05.43
HDIA frequency
input filter time
0.000s–10.000s
0.030s
○
P05.44
HDIB high-speed
pulse input
function selection
0: Set input via frequency
1: Reserved
2: Encoder input, used in combination with HDIA
0
◎
P05.45
Lower limit
frequency of
HDIB
0.000 kHz – P05.47
0.000
kHz
○
P05.46
Corresponding
setting of lower
-300.0%–300.0%
0.0%
○
