HD2 Series Inverter Function Parameter List
-173-
Function
code
Name
Description
Default
value
Modify
13: In pre-exciting
14: Overload pre-alarm
15: Underload pre-alarm
16: Simple PLC stage completed
17: Simple PLC cycle completed
18: Reach set counting value
19: Reach designated counting value
20: External fault is valid
21: Reserved
22: Reach running time
23: Virtual terminal output of Modbus/Modbus TCP
communication
24: Virtual terminal output of
POROFIBUS/CANopen communication
25: Virtual terminal output of Ethernet
communication
26: DC bus voltage established
27: Z pulse output
28: During pulse superposition
29: STO action
30: Positioning completed
31: Spindle zeroing completed
32: Spindle scale-division completed
33: In speed limit
34: Virtual terminal output of
EtherCAT/PROFINET/EtherNet IP communication
35: Reserved
36: Speed/position control switchover completed
37: Any frequency reached
38–40: Reserved
41: Y1 from the programmable card
42: Y2 from the programmable card
43: HDO from the programmable card
44: RO1 from the programmable card
45: RO2 from the programmable card
46: RO3 from the programmable card
47: RO4 from the programmable card
48: EC PT100 detected OH pre-alarm
49: EC PT1000 detected OH pre-alarm
