HD2 Series Inverter Function Parameter List
-178-
Function
code
Name
Description
Default
value
Modify
0: No function
1: Jogging
2: Reserved
3: Forward/reverse rotation switchover
4: Clear UP/DOWN setting
5: Coast to stop
6: Switch over the running command reference
mode in sequence
7: Reserved
Tens: Reserved
P07.03
Running
command
channel
switchover
sequence of
QUICK key
When P07.02=6, set the switchover sequence of
running command channel.
0: keypad control→terminal control→
communication control
1: keypad control←→terminal control
2: keypad control←→communication control
3: terminal control←→communication control
0
○
P07.04
Stop function
selection of
STOP/RST key
Validness selection of stop function of STOP/RST.
For fault reset, STOP/RST is valid under any
situation.
0: valid only for panel control only
1: valid for both panel and terminal control
2: valid for both panel and communication control
3: valid for all control modes
0
○
P07.05–
P07.07
Reserved
/
/
P07.08
Frequency
display
coefficient
0.01–10.00
Display frequency=running frequency× P07.08
1.00
○
P07.09
Speed display
coefficient
0.1–999.9%
Mechanical speed=120×display running
frequency×P07.09/number of motor pole pairs
100.0%
○
P07.10
Linear speed
display
coefficient
0.1–999.9%
Linear speed=mechanical speed×P07.10
1.0%
○
P07.11
Temperature of
rectifier bridge
module
-20.0–120.0°C
/
●
