HD2 Series Inverter Function Parameter List
-188-
Function
code
Name
Description
Default
value
Modify
1: Compensation method 2
Thousands place: PWM loading mode selection
0: Interruptive loading
1: Normal loading
P08.41
Overmodulation
selection
0x00–0x1111
Ones place:
0: Disable overmodulation
1: Enable overmodulation
Tens place
0: Mild overmodulation
1: Deepened overmodulation
Hundreds: Carrier frequency limit
0: Yes
1: No
Thousands: Output voltage compensation
0: No
1: Yes
0x1001
◎
P08.42
Reserved
P08.43
Reserved
P08.44
UP/DOWN
terminal control
setup
0x000–0x221
Ones: Frequency control selection
0: UP/DOWN terminal setup is valid
1: UP/DOWN terminal setup is invalid
Tens: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: All frequency modes are valid
2: Invalid for multi-step speed when multi-step
speed takes priority
Hundreds: Action selection during stop
0: Valid
1: Valid during running, clear after stop
2: Valid during running, clear after receiving stop
command
0x000
○
P08.45
UP terminal
frequency
incremental
integral rate
0.01–50.00Hz/s
0.50Hz/s
○
P08.46
DOWN terminal
0.01–50.00Hz/s
0.50Hz/s
○
