HD2 Series Inverter Function Parameter List
-197-
Function
code
Name
Description
Default
value
Modify
P10.14
Multi-step speed 6
When selecting multi-step speed running, the
multi-step speed is within the range of -fmax–
fmax, and it can be set continuously. The start/stop
of multi-step running is also determined by P00.01.
The inverter supports the setting of speeds of 16
steps, which are set by combined codes of
multi-step terminals 1–4 (set by S terminals,
corresponding to function codes P05.01–P05.06)
and correspond to multi-step speeds 0–15.
Output frequency
t
t
t
t
t
terminal 1
terminal 2
terminal 3
terminal 4
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
ON ON ON
ON ON ON ON ON
ON
ON
ON ONON
ON
ON
When terminals 1–4 are OFF, the frequency input
mode is set by P00.06 or P00.07. When terminals
1–4 are not all OFF, the frequency set by
multi-step speed will prevail, and the priority of
multi-step setting is higher than that of the keypad,
analog, high-speed pulse, PID, and
communication settings.
The relationship between terminals 1–4 is shown
in the table below.
Terminal 1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Terminal 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
Terminal 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Terminal 4
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
Step
0
1
2
3
4
5
6
7
Terminal 1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Terminal 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
Terminal 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Terminal 4
ON
ON
ON
ON
ON
ON
ON
ON
Step
8
9
10
11
12
13
14
15
0.0%
○
P10.15
Running time of
step 6
0.0s(min)
○
P10.16
Multi-step speed 7
0.0%
○
P10.17
Running time of
step 7
0.0s(min)
○
P10.18
Multi-step speed 8
0.0%
○
P10.19
Running time of
step 8
0.0s(min)
○
P10.20
Multi-step speed 9
0.0%
○
P10.21
Running time of
step 9
0.0s(min)
○
P10.22
Multi-step speed
10
0.0%
○
P10.23
Running time of
step 10
0.0s(min)
○
P10.24
Multi-step speed
11
0.0%
○
P10.25
Running time of
step 11
0.0s(min)
○
P10.26
Multi-step speed
12
0.0%
○
P10.27
Running time of
step 12
0.0s(min)
○
P10.28
Multi-step speed
13
0.0%
○
P10.29
Running time of
step 13
0.0s(min)
○
P10.30
Multi-step speed
14
0.0%
○
P10.31
Running time of
step 14
0.0s(min)
○
P10.32
Multi-step speed
15
0.0%
○
P10.33
Running time of
step 15
0.0s(min)
○
P10.34
Acceleration/
Detailed illustration is shown in the table below.
0x0000
○
