IMO HD2-3.7A-43 - Page 207

HD2 Series Inverter Function Parameter List
-198-
Function
code
Name
Description
Default
value
Modify
deceleration time
of steps 0–7 of
simple PLC
Function
code
Binary
Step
no.
ACC/
DEC
time 1
ACC/
DEC
time 2
ACC/
DEC
time 3
ACC/
DEC
time 4
P10.34
BIT1
BIT0
0
00
01
10
11
BIT3
BIT2
1
00
01
10
11
BIT5
BIT4
2
00
01
10
11
BIT7
BIT6
3
00
01
10
11
BIT9
BIT8
4
00
01
10
11
BIT11
BIT10
5
00
01
10
11
BIT13
BIT12
6
00
01
10
11
BIT15
BIT14
7
00
01
10
11
P10.35
BIT1
BIT0
8
00
01
10
11
BIT3
BIT2
9
00
01
10
11
BIT5
BIT4
10
00
01
10
11
BIT7
BIT6
11
00
01
10
11
BIT9
BIT8
12
00
01
10
11
BIT11
BIT10
13
00
01
10
11
BIT13
BIT12
14
00
01
10
11
BIT15
BIT14
15
00
01
10
11
Select corresponding acceleration/deceleration
time, and then convert 16-bit binary number into
hexadecimal number, finally, set corresponding
function code.
Acceleration/deceleration time 1 is set by P00.11
and P00.12; Acceleration/deceleration time 2 is set
by P08.00 and P08.01; Acceleration/deceleration
time 3 is set by P08.02 and P08.03; Acceleration
/deceleration time 4 is set by P08.04 and P08.05.
Setting range: 0x0000–0xFFFF
P10.35
Acceleration/
deceleration time
of steps 8–5 of
simple PLC
0x0000
○
P10.36
PLC restart mode
0: Restart from the first step, namely if the inverter
stops during running (caused by stop command,
fault, or power down), it will run from the first step
after restart.
1: Continue running from the step frequency when
interruption occurred, namely if the inverter stops
during running (caused by stop command or fault),
it will record the running time of current step, and
enters this step automatically after restart, then
0
◎
