IMO HD2-3.7A-43 - Page 232

HD2 Series Inverter Function Parameter List
-223-
Function
code
Name
Description
Default
value
Modify
expansion card
in card slot 1
detected.
P16.25
Identification
time for the
expansion card
in card slot 2
0.0–600.0s
If it is set to 0.0, offline fault will not be detected.
0.0s
○
P16.26
Identification
time for the
expansion card
in card slot 3
0.0–600.0s
If it is set to 0.0, offline fault will not be detected.
0.0s
○
P16.27
Communication
timeout period of
expansion card
in card slot 1
0.0–600.0s
If it is set to 0.0, offline fault will not be detected.
0.0s
○
P16.28
Communication
timeout period of
expansion card
in card slot 2
0.0–600.0s
If it is set to 0.0, offline fault will not be detected.
0.0s
○
P16.29
Communication
timeout period of
expansion card
in card slot 3
0.0–600.0s
If it is set to 0.0, offline fault will not be detected.
0.0s
○
P16.30
EtherCAT
communication
timeout time
(Reserved)
0.0–60.0s
5.0
○
P16.31
PROFINET
communication
timeout time
0.0–60.0s
5.0
○
P16.32
Received PZD2
0–31
0: Invalid
1: Set frequency (0–Fmax. Unit: 0.01Hz)
2: PID reference (-1000–1000, in which 1000
corresponds to 100.0%)
3: PID feedback (-1000–1000, in which 1000
corresponds to 100.0%)
4: Torque setting (-3000–+3000, in which 1000
corresponds to 100.0% of the motor rated current)
5: Setting of the upper limit of forward running
0
○
P16.33
Received PZD3
0
○
P16.34
Received PZD4
0
○
P16.35
Received PZD5
0
○
P16.36
Received PZD6
0
○
P16.37
Received PZD7
0
○
P16.38
Received PZD8
0
○
P16.39
Received PZD9
0
○
P16.40
Received PZD10
0
○
