HD2 Series Inverter Function Parameter List
-224-
Function
code
Name
Description
Default
value
Modify
P16.41
Received PZD11
frequency (0–Fmax. Unit: 0.01 Hz)
6: Setting of the upper limit of reverse running
frequency (0–Fmax. Unit: 0.01 Hz)
7: Upper limit of electromotive torque (0–3000, in
which 1000 corresponds to 100.0% of the motor
rated current)
8: Upper limit of braking torque (0–3000, in which
1000 corresponds to 100% of the motor rated
current)
9: Virtual input terminal command (Range: 0x000–
0x3FF, corresponding to
S8/S7/S6/S5/HDIB/HDIA/S4/S3/S2/S1)
10: Virtual output terminal command (Range:
0x00–0x0F, corresponding to RO2/RO1/HDO/Y1)
11: Voltage setting (special for V/F separation)
(0–1000, in which 1000 corresponds to 100% of
the motor rated voltage)
12: AO1 output setting 1 (-1000–+1000, in which
1000 corresponds to 100.0%)
13: AO2 output setting 2 (-1000–1000, in which
1000 corresponds to 100.0%)
14: High-order bit of position reference (signed)
15: Low-order bit of position reference (unsigned)
16: High-order bit of position feedback (signed)
17: Low-order bit of position feedback (unsigned)
18: Position feedback setting flag (position
feedback can be set only after this flag is set to 1
and then to 0)
19: Function parameter mapping (PZD2–PZD12
correspond to P14.49–P14.59)
20–31: Reserved
0
○
P16.42
Received PZD12
0
○
P16.43
Sent PZD2
0–31
0: Invalid
1: Running frequency (x100, Hz)
2: Set frequency (x100, Hz)
3: Bus voltage (x10, V)
4: Output voltage (x1, V)
5: Output current (x10, A)
0
○
P16.44
Sent PZD3
0
○
P16.45
Sent PZD4
0
○
P16.46
Sent PZD5
0
○
P16.47
Sent PZD6
0
○
P16.48
Sent PZD7
0
○
