HD2 Series Inverter Function Parameter List
-258-
Function
code
Name
Description
Default
value
Modify
P25.41
AI4 input signal
type
Range: 0–1
0: Voltage type
1: Current type
0
○
P25.42–
P25.45
Reserved
0–65535
0
○
P26––Output functions of expansion I/O card
Function
code
Name
Description
Default
value
Modify
P26.00
HDO2 output
type
0: Open collector high-speed pulse output
1: Open collector output
0
◎
P26.01
HDO2 output
selection
The same with P06.01
0
○
P26.02
Y2 output
selection
0
○
P26.03
Y3 output
selection
0
○
P26.04
Relay RO3
output selection
0
○
P26.05
Relay RO4
output selection
0
○
P26.06
Relay RO5
output selection
0
○
P26.07
Relay RO6
output selection
0
○
P26.08
Relay RO7
output selection
0
○
P26.09
Relay RO8
output selection
0
○
P26.10
Relay RO9
output selection
0
○
P26.11
Relay RO10
output selection
0
○
P26.12
Output terminal
polarity of
expansion card
0x0000–0x7FF
RO10, RO9…RO3, HDO2, Y3, Y2 in sequence
0x000
○
P26.13
HDO2 switch-on
delay
Used to define the corresponding delay of the level
variation from switch-on to switch-off.
0.000s
○
P26.14
HDO2 switch-off
0.000s
○
