HD2 Series Inverter Function Parameter List
-257-
Function
code
Name
Description
Default
value
Modify
limit of AI4
the anti-interference capacity of analog variables;
however, it will also degrade the sensitivity of
analog input.
Note: AI3 and AI4 can support 0–10V/0–20mA
input, when AI3 and AI4 select 0–20mA input, the
corresponding voltage of 20mA is 10V.
Setting range of P25.24: 0.00V–P25.26
Setting range of P25.25: -300.0%–300.0%
Setting range of P25.26: P25.24–10.00V
Setting range of P25.27: -300.0%–300.0%
Setting range of P25.28: 0.000s–10.000s
Setting range of P25.29: 0.00V–P25.31
Setting range of P25.30: -300.0%–300.0%
Setting range of P25.31: P25.29–10.00V
Setting range of P25.32: -300.0%–300.0%
Setting range of P25.33: 0.000s–10.000s
P25.33
Input filter time of
AI4
0.030s
○
P25.34
HDI3 high-speed
pulse input
function
0: Set input via frequency
1: Count
0
◎
P25.35
Lower limit
frequency of
HDI3
0.000 kHz – P25.37
0.000
kHz
○
P25.36
Corresponding
setting of lower
limit frequency of
HDI3
-300.0%–300.0%
0.0%
○
P25.37
Upper limit
frequency of
HDI3
P25.35 –50.000kHz
50.000
kHz
○
P25.38
Corresponding
setting of upper
limit frequency of
HDI3
-300.0%–300.0%
100.0%
○
P25.39
HDI3 frequency
input filter time
0.000s–10.000s
0.030s
○
P25.40
AI3 input signal
type
Range: 0–1
0: Voltage type
1: Current type
0
○
