HD2 Series Inverter Function Parameter List
-268-
Function
code
Name
Description
Default
Modify
unwinding mode by setting P90.01 to 1 or
changing the winding/unwiding switchover
terminals.
P90.02
Reel mechanical
transmission rate
0.01–600.00
=Motor rotation speed/Reel rotation speed=Reel
diameter/Motor shaft diameter
1.00
○
P90.03
Max. linear
speed
0.0–6000.0 (m/min)
1000.0
○
P90.04
Input source of
linear speed
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI
5: Main traction encoder frequency-division input
0
◎
P90.05
Linear speed set
through keypad
0.0–100.0%
20.0
○
P90.06
Diameter of main
traction
0.0–6000.0mm
99.0
○
P90.07
Main traction
drive ratio
0.000–60.000
1.000
○
P90.08
Linear speed
ACC time
0.00–600.00s
0.00
○
P90.09
Linear speed
DEC time
0.00–600.00s
0.00
○
P90.10
Tension setting
0x00–0x14
Ones place: Tension setting source
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI
Tens place: Multiplier of max. tension (P90.12)
0: 1
1: 10
0x00
◎
P90.11
Tension set
through keypad
0.0–100.0%
10.0
○
P90.12
Max. tension
When the tens place of P90.10 is 0, the setting
range is 0–60000N.
1000
○
