IMO HD2-3.7A-43 - Page 278

HD2 Series Inverter Function Parameter List
-269-
Function
code
Name
Description
Default
Modify
When the tens place of P90.10 is 1, the setting
range is (0–60000) *10N.
P90.13
Roll diameter
calculation mode
0: Not calculated
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI
5: Linear speed
6: Thickness (of wire)
7: Thickness (of strip)
0
◎
P90.14
Roll diameter
calculation delay
time
0.0–100.0s
1.0
○
P90.15
Min. roll diameter
0.0mm–P90.16
50.0
○
P90.16
Max. roll
diameter
P90.15–5000.0mm
1000.0
○
P90.17
Initial roll
diameter 1
P90.15–P90.16 (mm)
100.0
○
P90.18
Initial roll
diameter 2
P90.15–P90.16 (mm)
100.0
○
P90.19
Initial roll
diameter 3
P90.15–P90.16 (mm)
100.0
○
P90.20
Linear speed roll
diameter
calculation filter
time
0.000–60.000s
2.000
○
P90.21
Linear speed roll
diameter
calculation
restriction
0x00–0x11
Ones place:
0:No
1: Restrict changes in reverse direction
Tens place:
0: No
1: Automatic restriction according to running
frequency and material thickness
0x00
○
P90.22
Material
thickness
0.001–65.535mm
0.010
○
P90.23
Number of coils
per layer
1–10000
1
◎
