HD2 Series Inverter Function Parameter List
-274-
Function
code
Name
Description
Default
Modify
4: High-speed pulse HDI
P91.25
Tension taper set
through keypad
0.0–100.0%
30.0
○
P91.26
Tension taper
compensation
correction
0.0–5000.0mm
0.0
○
P91.27
Tension taper
curve selection
0–1
0: Inverse proportional curve
1: Multi-point curve
0
◎
P91.28
Roll diameter
value 1
0.0–5000.0mm
200.0
○
P91.29
Tension taper
coefficient for roll
diameter value 1
0.0–50.0%
3.0
○
P91.30
Roll diameter
value 2
0.0–5000.0mm
500.0
○
P91.31
Tension taper
coefficient for roll
diameter value 2
0.0–50.0%
7.0
○
P91.32
Reserved
0-65535
0
●
P91.33
Reserved
0-65535
0
●
P91.34
Reserved
0-65535
0
●
P91.35
Reserved
0-65535
0
●
P91.36
Reserved
0-65535
0
●
P91.37
Reserved
0-65535
0
●
P91.38
Reserved
0-65535
0
●
P91.39
Reserved
0-65535
0
●
P92––Customized tension control functions
Function
code
Name
Description
Default
Modify
P92.00
Pre-drive speed
gain
0.0–100.0%
100.0
○
P92.01
Pre-drive torque
limit
0–2
0: Set based on P03.20, P03.21
1: Set based on P93.02
2: Set based on the set tension
2
○
P92.02
Pre-drive torque
0.0–200.0%
100.0
○
