HD2 Series Inverter Expansion Cards
-356-
Signal
Port
Description
B1-
Z1+
Z1-
A2+
Pulse setting
1. Differential input of 5 V
2. Response frequency: 200 kHz
A2-
B2+
B2-
Z2+
Z2-
AO+
Frequency-divided
output
1. Differential output of 5 V
2. Supporting frequency division of 1–255, which
can be set through P20.16 or P24.16
AO-
BO+
BO-
ZO+
ZO-
U+
UVW encoder interface
1. Absolute position (UVW information) of the
hybrid encoder, differential input of 5 V
2. Response frequency: 40 kHz
U-
V+
V-
W+
W-
The following figure shows the external wiring of the HD2-E-PGI expansion card.
