HD2 Series Inverter Dimension Drawings
-371-
C.3 Inverter structure
Figure C-3 inverter structure diagram
C.4 Dimensions of AC 3PH 380V (-15%)–440V (+10%)
C.4.1 Wall mounting dimensions
W1
H1
D1 W2
H2
Figure C-4 Wall mounting diagram for 380V 1.5–37kW models
