HD2 Series Inverter Dimension Drawings
-370-
Appendix C Dimension Drawings
C.1 What this chapter contains
This chapter describes the inverter dimension drawings. The dimension unit used in the drawings is
millimeter (mm).
C.2 Keypad structure
C.2.1 Structure diagram
Installation hole dimensions and diagram for key installation without bracket
Ou
ter outline
of the keypad
2
-
M
3
×
8
tapping
screw
Panel
Keypad
109.3
71.3
28.5
16.8
2.5
109.3
56
6.7
71.3
58
2- ø4
1934.4
19
20.4
Figure C-1 Keypad structure diagram
C.2.2 Keypad installation bracket
Note: You can directly use M3 threaded screws or a keypad bracket to install the keypad externally.
For the 380V 1.5–75kW inverter models, you need to use optional keypad installation brackets. For
the 380V 90–500kW and the 660V 22–630kW inverter models, you can either use optional brackets
or install the standard keypad brackets externally.
Installation dimensionsKeypad adapter bracket
103
98
140
115
4-R12
Figure C-2 Keypad installation bracket (optional) for 380V 1.5–500kW and 660V 22–630kW models
