HD2 Series Inverter Dimension Drawings
-373-
W1
W2
D1
H1 H2
6- ø13.0
W2
Figure C-8 Wall mounting diagram for 380V 220–315kW models
Table C–1 Wall mounting dimensions of 380V inverter models (unit: mm)
Inverter model
W1
W2
W3
H1
H2
D1
Mounting
hole
Fixing
screw
1.5kW–2.2kW
126
115
-
186
175
185
Ø 5
M4
4kW–5.5kW
126
115
-
186
175
201
Ø 5
M4
7.5kW
146
131
-
256
243.5
192
Ø 6
M5
11kW–15kW
170
151
-
320
303.5
220
Ø 6
M5
18.5kW–22kW
200
185
-
340.6
328.6
208
Ø 6
M5
30kW–37kW
250
230
-
400
380
223
Ø 6
M5
45kW–75kW
282
160
226
560
542
258
Ø 9
M8
90kW–110kW
338
200
-
554
535
330
Ø 10
M8
132kW–200kW
500
180
-
870
850
360
Ø 11
M10
220kW–315kW
680
230
-
960
926
380
Ø 13
M12
C.4.2 Flange mounting dimensions
H1 H2
W1
W2
D1
D2
W3
W2
W4
H4
H2H3
Figure C-9 Flange mounting diagram for 380V 1.5–75kW models
