HD2 Series Inverter Optional Peripheral Accessories
-389-
Inverter model
Input reactor
DC reactor
Output reactor
HD2-38A-43
ACLC-18-4
Standard
OCLC-18-4
HD2-45A-43
ACLC-22-4
Standard
OCLC-22-4
HD2-60A-43
ACLC-37-4
Standard
OCLC-37-4
HD2-75A-43
ACLC-37-4
Standard
OCLC-37-4
HD2-92A-43
ACLC-45-4
Standard
OCLC-45-4
HD2-115A-43
ACLC-55-4
Standard
OCLC-55-4
HD2-150A-43
ACLC-75-4
Standard
OCLC-75-4
HD2-180A-43
ACLC-110-4
Standard
OCLC-110-4
HD2-215A-43
ACLC-110-4
Standard
OCLC-110-4
Note:
⚫ The rated input voltage drop of input reactors is 2%±15%.
⚫ The current adjustment coefficient on the input side of the inverter is higher than 90% after a DC
reactor is configured.
⚫ The rated output voltage drop of output reactors is 1%±15%.
⚫ The preceding table describes external accessories. You need to specify whether external or
built-in accessories are needed in your purchase order.
D.6.2 For parallel inverters
The following tables lists the reactor model selection for the inverters to be paralleled.
Table D–8 Reactor model selection for AC 3PH 380V (-15%)–440V (+10%)
Inverter
model
Input reactor model
DC reactor model
Output reactor model
280kW
ACLC-280-4 (Standard)
DCLC-280-4 (Optional)
OCLC-280-4 (Standard)
315 kW
ACLC-315-4 (Standard)
DCLC-315-4 (Optional)
OCLC-315-4 (Standard)
350 kW
ACLC-350-4 (Standard)
DCLC-400-4 (Optional)
OCLC-350-4 (Standard)
400 kW
ACLC-400-4 (Standard)
DCLC-400-4 (Optional)
OCLC-400-4 (Standard)
500 kW
ACLC-500-4 (Standard)
DCLC-500-4 (Optional)
OCLC-500-4 (Standard)
Note:
⚫ The rated input voltage drop of input reactors is 2%±15%.
⚫ The current adjustment coefficient on the input side of the inverter is higher than 90% after a DC
reactor is configured.
⚫ The rated output voltage drop of output reactors is 1%±15%.
⚫ DC reactors are externally connected. You need to specify whether external or built-in reactors
are needed in your purchase order.
Table D–9 Reactor model selection for AC 3PH 520V (-15%)–690V (+10%)
Inverter
model
Input reactor model
DC reactor model
Output reactor model
