HD2 Series Inverter Basic Operation Guidelines
-69-
Function
code
Name
Description
Default
value
9: Pulse frequency HDIB
10: EtherCAT/PROFINET/EtherNet IP
communication
11: Programmable card
12: Reserved
Note: For these settings, 100% corresponds to
the max. frequency.
P03.15
Setting source of
REV rotation
frequency upper
limit in torque
control
0: Keypad (P03.17)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus/Modbus TCP communication
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: Pulse frequency HDIB
10: EtherCAT/PROFINET/EtherNet IP
communication
11: Programmable card
12: Reserved
Note: For these settings, 100% corresponds to
the max. frequency.
0
P03.16
FWD rotation
frequency upper
limit set through
keypad in torque
control
0.00Hz–P00.03 (Max. output frequency)
50.00 Hz
P03.17
REV rotation
frequency upper
limit set through
keypad in torque
control
0.00Hz–P00.03 (Max. output frequency)
50.00 Hz
P03.18
Setting source of
electromotive
torque upper limit
0: Keypad (P03.20)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
0
