HD2 Series Inverter Basic Operation Guidelines
-89-
Setting
Function
Description
4
Output current (relative to
inverter)
0–Twice the inverter rated current
5
Output current (relative to
motor)
0–Twice the motor rated current
6
Output voltage
0–1.5 times the inverter rated voltage
7
Output power
0–Twice the motor rated power
8
Set torque value (bipolar)
0–Twice the motor rated current. A negative value
corresponds to 0.0% by default.
9
Output torque (absolute
value)
0 – +/- (Twice the motor rated torque)
10
AI1 input value
0–10V/0–20mA
11
AI2 input value
0V–10V. A negative value corresponds to 0.0% by
default.
12
AI3 input value
0–10V/0–20mA
13
High-speed pulse HDIA input
0.00–50.00kHz
14
Value 1 set through
Modbus/Modbus TCP
communication
0–1000
15
Value 2 set through
Modbus/Modbus TCP
communication
0–1000
16
Value 1 set through
PROFIBUS/CANopen/Device
Net communication
0–1000
17
Value 2 set through
PROFIBUS/CANopen/Device
Net communication
0–1000
18
Value 1 set through Ethernet
communication
0–1000
19
Value 2 set through Ethernet
communication
0–1000
20
High-speed pulse HDIB input
0.00–50.00kHz
21
Value 1 set through
EtherCAT/PROFINET/
EtherNET IP communication
0–1000. A negative value corresponds to 0.0% by
default.
22
Torque current (bipolar)
0–Triple the motor rated current. A negative value
corresponds to 0.0% by default.
23
Exciting current
0–Triple the motor rated current. A negative value
