HD2 Series Inverter Basic Operation Guidelines
-90-
Setting
Function
Description
corresponds to 0.0% by default.
24
Set frequency (bipolar)
0–Max. output frequency. A negative value
corresponds to 0.0% by default.
25
Ramp reference frequency
(bipolar)
0–Max. output frequency. A negative value
corresponds to 0.0% by default.
26
Running speed (bipolar)
0–Synchronous speed corresponding to max. output
frequency. A negative value corresponds to 0.0% by
default.
27
Value 2 set through
EtherCAT/PROFINET/EtherN
et IP communication
0–1000
28
AO1 from the Programmable
card
0–1000
29
AO2 from the Programmable
card
0–1000
30
Running speed
0–Twice the motor rated synchronous speed.
31
Output torque (bipolar)
0–Twice the motor rated torque. A negative value
corresponds to 0.0% by default.
32
AI/AO temperature detection
output
AO value of AI/AO temperature detection
33–63
Reserved
Related parameter list:
Function
code
Name
Description
Default
value
P06.00
HDO output type
0: Open collector high-speed pulse
output
1: Open collector output
0
P06.14
AO1 output selection
0: Running frequency (0–Max. output
frequency)
1: Set frequency (0–Max. output
frequency)
2: Ramp reference frequency (0–Max.
output frequency)
3: Rotational speed (0–Speed
corresponding to max. output
frequency)
4: Output current (0–Twice the inverter
rated current)
0
P06.15
Reserved
0
P06.16
HDO high-speed pulse output
0
