Chapter 3 Program Tools 56
(4
)
S
ET (system setting)
content
default
ID SET
ID SET
01

ID setting (00~99)
REMOTE I/O
REMOTE I/O
N

Remote I/O Mode
(N: none M: Master S: Slave)
BACK LIGHT
BACK LIGHT
×

Back light mode
(√: always light ×: light for 10s after pressed.)
M KEEP
M KEEP
√

M: non-Volatile (√:Volatile ×: Non- Volatile)
I/O NUMBER
I/O NUMBER
0

Setting expansion, I/O module number (0~3)
I/O ALARM
I/O ALARM
√

Siren setting when is not available to Expansion
I/O Points (√:Yes ×:N o )
C KEEP
C KEEP
×

in stop/run switching, Counter Present Value
Keeping (√:Yes ×:No)
Z SET
Z SET
×

Enable or disable keypad input Z01-Z04
(√:enable ×:disable)
RS485 SET
RS485 SET
03

Setting the form and baud rate of RS-485
DATA REG.
DATA REG.
U

Setting the Data Register type
(U: 16bit-unsiged S: 16bit-sign)
MEMORY SET
M/S SET
※ M KEEP function is available for keeping M status and current value of T0E/T0F when power is re-supplied
after loss.
Now Press:
↑ ↓ ← →
Move the cursor
SEL
Begin to edit.
‘SEL’ then ‘←/→’
Move the cursor for ‘ID SET’ item and ‘RS485 SET’ item
‘SEL’ then ‘↑ /↓’
1. ID SET = 00~99 ; I/O NUMBER = 0~3
2. REMOTE I/O = N⇔M⇔S⇔N
3.
B
ACK LIGHT ; C KEEP ; Z SET = ×⇔√
4. M KEEP; I/O ALARM = √⇔×
5. RS485 SET = (0~3)(0~5)
6. DATA REG. = U⇔S
OK
Confirm the Edition Data
ESC
1. Cancel the setting when pressed ‘SEL’
2. Back to Main Menu(save edit data)
※
When IO LINK is selected, ID setting range is 0~7, which should be continuous.
ID=0 default as Master, ID=1~7 default as Slave.
※ When REMOTE I/O is selected, the distribution of the remote I/O is as follows:
Master
Slave
Remote Input
X01~X0C
←
I01~I0C
Remote Output
Y01~Y08
→
Q01~Q08
